4channels WIFI NVR Kit with 10inch display is new generation NVR（Net Video Recoder），supports WIFI video input and supports Max. 4channels 1080P（2Mp）Wireless real-time video view，video encode and replay. And the WIFI IPCAM adopts advanced video coding, Embedded, Record, Network and wireless etc. technology. No need cable, easy to install and support plug and play.

Application

Features

1.Megapixel HD video, image is more clear.

2.Built-in wireless Router which support 802.11b/g/n,150Mbps,good stability and good ability to resist interference.

3.Samrt stream regulation to ensure the stability of connection.

4.Strong WIFI signal, can pass 2-3walls.

5.No need WIFI match, plug and play.

6.Support P2P/DHCP/DDNS/PPPoE/E-Mail/FTP etc.

7.Easy to install, not require professional knowledge.

8.Support motion detecting, send alarm signals by email or FTP upload pics etc.

9.Support wired and wireless mix use, suit to different sites.

10.Support cloud, remote connection quickly, support mobile, Ipad, PC etc. platform.

11. 10.1inch high quality LCD display

Specification

WIFI NVR

Model DLX-WN4L10

Video input 4channels 720P/960P/1080P

HDMI output 1ch, resolution: 1024x768,1366x768,1440x900,1920x1080p

VGA output 1ch, resolution: 1024x768,1366x768,1440x900,1920x1080p

Record resolution 720P/960P/1080P

Replay 4channels

Record/capture model Manual record, timing record, Motion Detection and Alarm record

Display 10.1 inch LCD

Storage model one SATA

Storage capacity Each SATA support Max.4TB HD

Internet ports One RJ45 10M/100M, two WIFI antenna

USB Two USB2.0

Power consumption ≤5W

Size（mm） 258×210×42

Power supply DC12V

WIFI IP camera

Model DLX-WF3A10 DLX-WF3A13 DLX-WF3A20

Pixel 1Mp 1.3Mp 2Mp

Sensor 1/4”CMOS 1/3”CMOS 1/2.8”CMOS

Lens 4mm/6mm

Stream Dual streams

1280x720@25fps

640x360@25fps Dual streams

1280x960@25fps

640x360@25fps Three streams

1920x1080@30fps

640x480@30fps

320x240@30fps

Resolution 1280x720 16:9 1280x960 4:3 1920x1080 16:9

Min. Illumination Color:0.1Lux B/W:0.01Lux

Private areas 4 areas

IRLED 3pieces Arrays LED, double IR-CUT filter

IR distance 30meters

Connector RJ45/WIFI 802.11b/g/n RJ45/WIFI 802.11b/g/n RJ45/WIFI 802.11b/g/n/(2.4G/5.8G two frequency support)

Power supply DC12V

Power consumption ≤6W

Packing list

No Product name Quantity Unit

1 WIFI NVR 1 piece

2 Screws（for install HD in NVR ） 1 bag

3 USB mouse 1 piece

4 1meter UTP cable（IPC） 1 piece

5 DC 12V2A power adapter (for NVR ) 1 piece

6 User manual 1 piece

7 WIFI IP camera 4 piece

8 DC 12V1A power adapter（for IPC） 4 piece
