Horizontal Rotation Range : 360°

Tilt Rotation Speed : 100o/s

Tilt Rotation Range : 90o

Auto Flip: Horizontal 180°, Vertical 90°

Auto Control IR LED: PWM

360 Scan: 1-64 levels setting available

A-B Scan: User programmable

A-B Scan speed : 1-64 levels setting available

Dwell Preset: 5-60s interval available

Preset points : 220

Go to preset speed; 1-64 levels available

Guard Tours: 4 groups

Guard Points: Max.16 points, dwell time user selectable

Pattern Scan: 4 pcs

Pattern Scan Record: Max.15 minutes, max.512 commands

PWR on Action: Memory/Pattern 1/Tour 1/360° scan/A-B scan/Preset 1-8/None

Communication Protocol: Pelco-D, Pelco-P

Communication: RS485

Baud Rate: 1200/2400/4800/9600bps

Privacy Mask : 8-24pcs (according to zoom module type)

OSD Menu :Multiple Languages: English, Spanish, French, German, Italian etc.

3D Location: Support

Time Scheduling Function: 8 tasks

Operating Temperature: Indoor: 0°~ +40° Outdoor: -40°~ +60°

Operating Humidity : ≤95% Non Condensing

Heater & Blower : Auto temperature control

Power: AC/DC15-28V ≤3A

IR Illumination Distance : 150M

Power Consumption: ≤ 20W

Lightning Protection: Transient voltage 6000V

Compatible Camera: SONY, SAMSUNG, LG, CNB etc.

IR LED: ?22=6, ?16=5
