Horizontal Rotation Range : 360°

Tilt Rotation Speed: 30°/s

Tilt Rotation Range : 90°

Auto Flip: Horizontal 180°, Vertical 180°

Ratio Speed: Support

Auto Control IR LED: PWM

A-B Scan: User programmable

A-B Scan Speed : 0-64 levels setting available

Dwell Preset: 02-60s interval available

Preset Points : 220

Go to Preset Speed: 01-64 levels available

Guard Tours: 3 groups

Guard Points: Max.16 points, dwell time user selectable

Park Time: 0-60mins available

PWR on Action: Memory/No Action/A-B scan/360° scan/Home/Tour 1-3

Privacy Mask: 8-24pcs (according to zoom module type)

Communication Protocol: Pelco-D,Pelco-P

Communication; RS485

Baud Rate: 1200/2400/4800/9600bps

Operating Temperature; Indoor: 0°~ +40° Outdoor: -40°~ +60°

Operating humidity : ≤95% Non Condensing

Heater & Blower : Auto temperature control

Power: AC/DC15-28V ≤3A (standard power: AC24V 3A)

IR Illumination Distance : 150M

Power Consumption: ≤ 20W

Lightning Protection: Transient voltage 6000V

Compatible Camera: SONY, SAMSUNG, LG, CNB etc.

IR LED: ?22=6, ?16=5
