Tilt Rotation Speed : 0.02 ～120°/s

Horizontal Rotation Range : 360°

Tilt Rotation Range: 93°

Auto Flip: Horizontal 180°, Vertical 93°

Ratio Speed : Support

Auto Control IR LED: PWM

360° Scan: 1-9 grades setting available

A-B Scan: User programmable

A-B Scan Speed : 1-9 grades setting available

PWR on Action: Memory/Pattern 1/Tour 1/360 scan/AB scan/Preset 1-8/None

Park Time: 1-60mins setting available

Dwell Preset: 5-60s interval available

Preset Points : 220

Go to Preset Speed: 200°/s

Guard Tours: 4 groups

Guard Points: Max.16 points, dwell time user selectable

Pattern Scan: 4 pcs

Pattern Scan Record: Max.15 minutes, max.512 commands

3D Location: Support (DH-SD1)

Time Scheduling Function: 8 tasks

Communication Protocol: Pelco-D, Pelco-P

Communication: RS485

Baud Rate: 1200/2400/4800/9600bps

Privacy Mask : Support (according to camera module type)

Operating Temperature: Indoor: 0°~ +40° Outdoor: -40°~ +60°

Operating Humidity : ≤95% Non Condensing

Heater & Blower : Auto temperature control

Power: AC/DC 15-28V ≤3A

IR Illumination Distance : 50M

Power Consumption: ≤ 15W

Lightning Protection: Transient voltage 6000V

Compatible Camera: SONY, HITACHI, SAMSUNG, LG, CNB etc.

IR LED: ?16=6
