Horizontal Rotation Range : 360°

Tilt Rotation Speed : 50o/s

Tilt Rotation Range : 93°

Auto Flip: Horizontal 180°, Vertical 180°

Auto Control Laser LED: PWM

A-B Scan: User programmable

A-B Scan Speed : 01-64 level setting available

Dwell Preset: 01-60s interval

Preset Points : 220

Go to Preset Speed: 01-64 level setting available

Guard Tours: 3 groups

Guard Points: Max.16 points, dwell time user selectable

Park Time: 1-60mins available

PWR on Action: Memory/No Action/A-B scan/360° scan/Home/Tour 1-3

Communication Protocol: Pelco-D, Pelco-P

Communication: RS485

Baud Rate : 1200/2400/4800/9600bps

OSD Menu : English

Operating Temperature: -40°- +60°

Operating Humidity : ≤95% Non Condensing

Heater & Blower : Auto temperature control

Power: AC/DC15-28V ≤3A

Laser Illumination Distance : 240M

Power Consumption: ≤ 20W

Lightning Protection: Transient voltage 6000V

Compatible Camera: SONY, LG, CNB, SAMSUNG etc.

Laser Angle of Illumination: 5-60 °

Spectrum Width: ＜5nm

Central Wavelength: 808nm
