.FR Carrier Frequency: 433.92MHz, 868.35MHz (crystal-controlled)

.Transmitting Power: Less than 10mW

.Modulation: Frequency Shift Key (FSK) type

.System ID Code: 268 million combinations

.Working Power: 3.0VDC 1.3AH (CR123) Lithium Battery

.Battery Power Supervision: 2.4VDC for Low Battery Warning; .2.35VDC for Dying battery Warning

.Typical Battery Life: Up to 10 years in storage

.Power Consumption: 26uA in standby; 15mA in transmission

.Transmitting Time: 3 Seconds on each data-stream transmission

.Status Supervision Report: Every 5 hours

.Dual-color LED: Red – in Transmission / Green – in Low Battery Power Warning

.Interchangeable Lens type and Coverage:

Dense Wide Angle: 9m, 101 degree sector

Long Range: 30m long, 3m wide

Vertical Barrier: 15m long, 7m high vertical barrier

Animal Alley: 12m, 100 degree sector

.Operating Temperature: -10℃ to +50℃

.Dimension: 108mm L x 80mm W x 46mm H
