Built-in CD-RW/DVD-RW

User friendly Graphic User Interface

External keyboard control

Remote PTZ control

USB Mouse Control

Secure Embedded Proprietary Linux Operating System

Supports variable video outputs at the same time ; TV-Out, Video-Out, S-Video, Loop-out, Spot(9/16ch only)

Daylight-Saving Time

Free DDNS for Dynamic IP

Full remote system Access, Search and Backup via LAN and xDSL

Simultaneously monitors & controls multiple remote DVRs

Remote monitoring via Internet Explorer

Auto-Time sync

Auto-backup thru external storage

Specifications

Description VD-16400 VD-16100 VD-9100

Video Input Channel 16ch 9ch

Signal/ Level Dip Switch Auto Detection(NTSC/PAL),Composite 1.0Vp-p±10%, 75Ω

Output Display TV-Out(Composite 1.0Vp-p, 75Ω),VGA-Out(15Pin D-Sub), S-Video

Loop 16ch/ SPOT 1ch 9ch/ SPOT 1ch

Audio Input Channel 16ch 4ch

Compression G.723 ADPCM

Sensor/Alarm Input 16ch 9ch

Output 4ch

Display Rate NTSC PAL NTSC PAL NTSC PAL

480fps 400fps 480fps 400fps 270fps 225fps

Mode 1,4,9,16 & PIP, POP 1,4,9 & PIP, POP

Recording Compression MPEG4 (Hardware Codec)

Resolution/Rate NTSC/ PAL NTSC PAL NTSC PAL NTSC PAL

360x240 / 360x288 480fps 400fps 120fps 100fps 120fps 100fps

720x240 / 720x288 240fps 200fps 60fps 50fps 60fps 50fps

720x480 / 720x576 120fps 100fps 30fps 25fps 30fps 25fps

Quality 4 Level

Mode Continuous, Event(Motion, Sensor), Schedule, Manual

Motion Detection Sensitivity 1~9

Pre Alarm Recoding Max. 30sec None, 2sec, 4sec, 6sec, 8sec, 10sec

Post Alarm Recoding Max. 120sec 10sec, 30sec, 1min, 5min, 10min

Search Playback Mode Step Forward/Reverse, Play/Pause, Stop, Fast Forward/Reverse

Mode Time, Event, Calendar

Storage Internal HDD Interface Type SATA

Max HDD Number 4 HDD

Backup Device CD-RW, DVD-RW, USB Memory

ETC Operation System Embedded Linux

PTZ Camera Control RS-485

Network ADSL/ Static IP/ Dynamic IP(Available Dynamic DNS)

Dimension(W x D x H) TBA 430 x 380 x 95 mm(16.9 x 15 x 3.7 inch)

Weight TBA 5.5 kgs (12.1 lbs)
