Built-in CD-RW/DVD-RW

Remote PTZ control

Watermarking

External Keyboard Control

On screen display

Secure Embedded Proprietary Linux Operating System

Supports variable video outputs at the same time ;TV-Out, Video-Out, S-Video, Loop-out, Spot(9/16ch only)

Auto-detection on video NTSC/PAL format

Full remote system Access, Search, Backup & PTZ control via LAN and xDSL

Built-in web server for easy remote Access & Search via Internet Explorer

Multiple remote site Access & Control (EnTMS)

Specifications

Description VC-16100 VC-9100 VC4100

Video Input Channel 16ch 9ch 4ch

Signal/ Level Auto Detection(NTSC/ PAL), Composite 1.0Vp-p 10%, 75Ω

Output Display TV-Out(Composite 1.0Vp-p, 75Ω), VGA-Out(15Pin D-Sub), S-Video

Loop 16ch/ SPOT 1ch 9ch/ SPOT 1ch 4ch/ No Spot

Audio Input Channel 4ch

Compression ADPCM

Sensor/Alarm Input 16ch 9ch 4ch

Output 4ch

Display Rate NTSC PAL NTSC PAL NTSC PAL

480fps 400fps 270fps 225fps 120fps 100fps

Mode 1,4,9,16 & PIP, POP 1,4,9 & PIP, POP 1,4

Recording Compression MPEG4(Hardware Codec)

Resolution/Rate NTSC/ PAL NTSC PAL NTSC PAL NTSC PAL

360x240 / 360x288 120fps 100fps 120fps 100fps 120fps 100fps

720x240 / 720x288 60fps 50fps 60fps 50fps 60fps 50fps

720x480 / 720x576 30fps 25fps 30fps 25fps 30fps 25fps

Quality 4 Level

Mode Continuous, Event(Motion, Sensor), Schedule, Manual

Motion Detection Sensitivity 1~9

Pre Alarm Recoding None, 2sec, 4sec, 6sec, 8sec, 10sec

Post Alarm Recoding 10sec, 30sec, 1min, 5min, 10min

Search Playback Mode Step Forward/Reverse, Play/Pause, Stop, Fast Forward/ Reverse

Speed x1, x2, x4, x8, x16, x32, x64, x128

Mode Time, Event, File

Storage Internal HDD Interface Type SATA

Max HDD Number 4 HDD

Backup Device CD-RW, DVD-RW, USB Memory

ETC Operation System Embedded Linux

PTZ Camera Control RS-485

Network ADSL/ Static IP/ Dynamic IP(Available Dynamic DNS)

Dimension(W x D x H) 430 x 380 x 95 mm 380 x 330 x 68 mm

(16.9 x 15 x 3.7 inch) (15 x 13 x 2.7 inch)

Weight 5.5 kgs (12.1 lbs) 3.5 kgs (7.7 lbs)
