Product Parameter Parameter Description

Fail Safe Locked when energized

Face Plate 205Lx35WX41H(mm)

Strike 90Lx25Wx2H(mm)

Bolt 16mmDIA,stainless steel 16mm throw

Voltage 12VDC

Start Current 900mA

Standby Current 120mA

Solid Bolt polishing housing, 800Kg Holding Force

Suitable For Woodeng Door,Glass Door,Metal Door,Glass Door

Signal Output Door status Output,NC/COM

Surface Temp Low Temperature

Induction Distance 8mm

Operating temp -10～+55℃(14~131F)

Operating Humidity 0～90%(non-condensing)

Special Designed Tested to 500000 cycles

Face place material High Aluminum,Carrulous Line Finished

Weight 0.7kg
