• Voltage: 115VAC, 60Hz, 2.5A or 230VAC, 50/60Hz, 1.3A.
• Fusing: 5A/250V.

Power Output

• Maximum Power: Eight (8) PoE+ (30W) ports or two (2) Hi-PoE (60W) ports.
• IEEE 802.3at (30W) and IEEE 802.3af (15W) compliant.
• 115W total power.
• Integral surge protection.
• Fiber Ports: Two (2) Gigabit SFP ports.

• Six (6) 10/100 Mbps and two (2) 10/100/1000 Mbps ports.
• Connectivity: RJ45, auto-crossover.
• Wire type: 4-pair CAT5 or better-structured cable.
• Distance: up to 100m.
• Speed: 10/100/1000 Mbps, half/full duplex, auto negotiation

​​Indicators (LED)

• Individual PoE On LEDs for each port.
• Individual IP Link status, 10/100Base-T/active LEDs for each port.
• ALOS LED indicates fiber connection for SFP port.
• Heartbeat LED indicates proper operation of the unit.

• Remote network management allows for camera/device reset and monitoring.
• Provides local and/or remote access to critical information via LAN/WAN.
• Email and Windows Dashboard Alert notifications report real-time diagnostics.
• Event log tracks history.




•
