● Thin profile and small footprint

● 7” capacitive touch screen

● Reception of a HD picture from door phones

● Two-way communication with SIP devices

● Powered by PoE or external source

● Supports US or European electrical wall box mounting

Touch Screen Display

Display Type: Active matrix TFT, transmissive type

Size: 7 inch (176 mm) diagonal

Aspect Ratio: 16:9

Resolution: 1024x600

Brightness: 300nits (cd/m²)

Contrast: 800:1

Color Depth: 24-bit, 16M colors

Illumination: Edgelit LED

Viewing Angle: ±70° horizontal, ±70° vertical

Touch Screen: Projected Capacitive

Wireless

Built-in Wi-Fi (2.4GHz, IEEE 802.11 /b/g/n) (For C315W only)

Video

Streaming Formats: H.264

Audio

Features: Built-in microphone and speaker

Memory

RAM: 1GB

Flash: 8GB

Communications

Ethernet: 2x10/100 Mbps ports, auto-switching, auto-discovery, auto-negotiating, full/half duplex, DHCP, IEEE802.3af compliant

Alarm Out: 1x Alarm output relay (Dry Contact)

Alarm In: 8x Alarm input terminals

Bell In: 1x Bell input terminal

RS485: 1x RS485 communication port

Environmental

Temperature: 14° to 112°F (-10° to 45°C)

Humidity: 10% to 90% (non-condensing)

Mechanical Parameters

Dimensions (W x H x D): 200 x 132 x 17.5 mm

Application Scenarios

Villas

Apartment complexes

Home automation systems

Modern interiors
