● Intuitive Android Operating System

● Premium audio and video quality

● Home automation integration

● Android 6.0/SIP/RTSP/PoE

At a Glance

Ultra-clear, stylish appearance

Thin profile and small footprint

7” capacitive touch screen with energy saving mode

1M pixels CMOS camera (For IT82A and IT82C only)

Design with internal antenna, support IEEE802.11n (For IT82A and IT82W only)

Reception of a HD picture from the door communicator

Two-way communication with other units in the network, based on SIP v2.0 protocol

Powered by PoE or external source

Touch Screen Display

Display Type: Active matrix TFT, transmissive type

Size: 7 inch (176 mm) diagonal

Aspect Ratio: 16:9

Resolution: 1024x600

Brightness: 300nits (cd/m²)

Contrast: 800:1

Color Depth: 24-bit, 16M colors

Illumination: Edgelit LED

Viewing Angle: ±80° Left, ±80° Right,

Viewing Angle: ±60° Upper, ±70° Lower

Touch Screen: Projected Capacitive

Camera

Camera: 1M pixels, CMOS (For IT82A and IT82C only)

Buttons

Hard Keys: 5 capacitive pushbuttons, programmable, pre-labeled with icons for “SOS”, “Message”, “Live View”, “Dial”, and “Unlock”

Memory

RAM: 2GB

Flash: 8GB

Communications

Ethernet: 2x10/100 Mbps ports, auto-switching, auto-discovery, auto-negotiating, full/half duplex, DHCP, IEEE802.3af compliant

Wireless

Antenna: 1 internal antenna (For IT82A and IT82W only)

Video

Streaming Formats: H.264

Audio

Features: Built-in microphone and speaker

Environmental

Temperature: 14° to 112°F (-10° to 45°C)

Humidity: 10% to 90% (non-condensing)

Mechanical Parameters

Dimensions (W x H x D): 232 x 160 x 21 mm

Application Scenario

Villas

Apartment complexes

Home automation systems

Modern interiors
