Image Sensor: Sharp or Sony 1/4”color CCD,1/3”color CCD, CMOS

Without audio and IR

TV system: PAL/NTSC

Scanning system: 2:1 interlace

Synchronize system: internal

Horizontal synchronize frequency: 15.625 to 15.734kHz

Vertical synchronize frequency: 50 to 60Hz

Video output: 1.0vp-p, 75ohm

Gamma consumption: 0.45

AGC: automatic

S/N ratio: better than 48dB

White balance: automatic

Electronic shutter: 1/60 (NTSC)/1/50 (PAL) to 1/10,000 seconds

BLC: automatic

Current consumption: 100mA

Power supply: 12V DC

Operating temperatures: -20 to 70°C, RH 95% maximum

Storage temperatures: -40 to 85°C, RH 95% maximum

Lens: f = 3.6mm

Lens angle: 69°

Serial products:

AS-8133 Sharp 1/4 CCD， 420TVL，1.0Lux/F1.2，Lens 3.6mm

AS-8134 CMOS， 420TVL，1.0Lux/F1.2，Lens 3.6mm

AS-8135 Sony 1/4 CCD，420TVL，0.5Lux/F1.2，Lens 3.6mm

AS-8136 Sony 1/3 CCD，420TVL，0.2Lux/F1.2，Lens 3.6mm

AS-8137 Sony 1/3 CCD，480TVL，0.2Lux/F1.2，Lens 3.6mm

Reference:

TV Line PAL(H x V) NTSC(H x V)

420TVL 500 x 582 pixels 510 x 492 pixels

480TVL 752 x 582 pixels 768 x 494 pixels

520TVL 752 x 582 pixels 768 x 494 pixels

600TVL 976 x 582 pixels 976 x 494 pixels

650TVL 976 x 494 pixels 976 x 582 pixels

700TVL 1020H x 596 pixels 1020H x 508 pixels
