CCD type: Sony Sharp CCD or CMOS

Scanning system: PAL/NTSC

Resolution:420TVL/480TVL

S/N ratio: >=48dB

Video output: 1.0Vp-p/75

AGC: AGC On/Off switchable

White balance: AWB On/Off switchable

Backlight compensation: On/Off switchable

Exposure mode: EE/AI switchable

Electronic shutter: 1/50(1/60) to 1/100000 seconds

Gamma correction: 0.45

Synchronizations system: internal synchronization

Auto iris control: video/DC switchable

Lens: C/CS

Power supply: 12V DC +_5%

Operating temperature: -20 to 50 degrees Celsius

Serial products:

AS-8203 Sharp 1/4 CCD， 420TVL，1.0Lux/F1.2, Current 50MA, Without Lens

AS-8204 CMOS， 420TVL，1.0Lux/F1.2, Current 50MA, Without Lens

AS-8205 Sony 1/4 CCD，420TVL，0.5Lux/F1.2, Current 60MA, Without Lens

AS-8206 Sony 1/3 CCD，420TVL，0.2Lux/F1.2, Current 80MA, Without Lens

AS-8207 Sony 1/3 CCD，480TVL，0.2Lux/F1.2, Current 70MA, Without Lens

Reference:

TV Line PAL(H x V) NTSC(H x V)

420TVL 500 x 582 pixels 510 x 492 pixels

480TVL 752 x 582 pixels 768 x 494 pixels

600TVL 976 x 582 pixels 976 x 494 pixels

650TVL 976 x 494 pixels 976 x 582 pixels

700TVL 1020 x 596 pixels 1020 x 508 pixels
