Image sensor: 1/4” Sharp CCD or 1/3” Sony CCD

Megapixels: PAL: 512 x 582

NTSC: 512 x 492

Scanning system: PAL/NTSC

Horizontal resolution: 420TVL

Synchronization: internal

Minimum illumination: 0.8 lux

Electronic shutter: 1/50 (1/60) to 1/100,000 seconds

White balance: automatic

Lens: standard 3.7mm pinhole lens

S/N ratio: ≥48dB

Gamma correction: 0.45

Video output voltage: 1Vp-p, 75Ω

Power supply: 12V DC, 500 to 1,000mA

Operating temperature: -20 to 50°C

Serial products:

AS-8503 Sharp 1/4 CCD，420TVL，1Lux/F1.2（Without Bracket），3.7mm pin lens, Current 50MA

AS-8506 Sony 1/3CCD，420TVL，0.8Lux/F1.2（Without Bracket），3.7mm pin lens, Current 60MA
