Image Sensor: Sharp or Sony1/4”color CCD, 1/3”color CCD, CMOS

TV system: PAL/NTSC

Scanning system: 2:1 interlace

Synchronize system: internal

Minimum illumination: 0 lux (IR on)

S/N ratio: ≥48dB

Video output: 1.0Vp-p, 75II composite, BNC x 1

Gamma ratio: ≥0.45

Focal length: 6mm fixed lens

Viewing angle: Vertical: 92°/53°

Zoom ratio: fix

Control mode: fix

Day/night: auto

Backlight compensation: auto

White balance: auto

Gamma characteristic: ≥0.15

Electronic shutter:

PAL: 1/50 to 1/100,000 seconds

NTSC: 1/60 to 1/100,000 seconds

Infrared LED: ?5, 36pcs IR LED

IR distance: 25 meters

Infrared spectrum: 850nm

Operating temperature: -10 to +50°C

Storage temperature: -40 to +60°C

Vandal-proof casing: IP66

Input voltage/current: DC 12V/500mA

Adapter requirement: DC 12V/1000mA

Serial products:

AS-8413 Sharp 1/4 CCD, 420TVL, 0LUX(With IR On), 36pcs F5 IR Lights, 25m distance, 6mm, 3.6mm Lens (Without Bracket)

AS-8414 CMOS, 420TVL, 0LUX(With IR On) , 36pcs F5 IR Lights, 25m distance, 6mm,3.6mm Lens (Without Bracket)

AS-8415 Sony 1/4 CCD, 420TVL, 0LUX(With IR On) , 36pcs F5 IR Lights, 25m distance, 6mm 3.6mm Lens (Without Bracket)

AS-8416 Sony 1/3 CCD, 420TVL, 0LUX(With IR On) , 36pcs F5 IR Lights, 25m distance, 6mm 3.6mm Lens (Without Bracket)

Reference

TV Line PAL(H x V) NTSC(H x V)

420TVL 500 x 582 pixels 510 x 492 pixels

480TVL 752 x 582 pixels 768 x 494 pixels

520TVL 752 x 582 pixels 768 x 494 pixels

600TVL 976 x 582 pixels 976 x 494 pixels

650TVL 976 x 494 pixels 976 x 582 pixels

700TVL 1020H x 596 pixels 1020H x 508 pixels
