8 CH BNC Video Input, 2 CH Video Output (Main & Call), 1CH VGA Output

H.264 Compression, Real Time Display 240fps Display Rate

Display Resolution: 704 x 576 (PAL) / 720 x 480 (NTSC)

Recording Resolution: D1 50fps 704 x 576 (PAL) / 60fps 704 x 480 (NTSC)

Half D1 100fps 704 x 288 (PAL) / 120fps 720 x 240 (NTSC)

CIF: 200fps 352 x 288 (PAL) / 240fps 360 x 240 (NTSC)

Manual / Schedule / Remote / Motion Recording

4 CH Audio Input 2 CH Audio Output, 8 CH Alarm Input 1Ch Alarm Output

Support Up to 2 Units Sata Harddisk (Max 1 TB)

Support PTZ Control, 2-8X Digital zoom

Support Network Remote Recording & Back-up, Pendrive Back up (USB 2.0)

Support IE TCP/IP, PPPoE, DHCP, DDNS

Remote Access & Surveillance with IE Browser, CMS Software Video Mobile Phone Surveillance Software

Watch Dog Feature, Video Loss Detection, Power Loss Recovery Function, Email images to FTP notification

Support Video Mobile Phone Surveillance Software (Symbian, W indows Mobile, JAVA, iPhone, Blackberry, Android)

IR Remote Controller & USB Mouse Control
