Image Sensor 1/4" SONY Super HAD CCD

Effective Pixels NTSC:811 x 508 pixels PAL:795 x 596 pixels

Scanning System Internal / VD-Lock

Minimum Illumination 0.7Lux@F1.8; 0.05 Lux(F1.8,Sen-up) 5600oK ); Color/0.92 Lux@F1.8(B/W)

Resolution 600 TVL

S/N Ratio 48dB ( MIN ) / 52dB ( TYP ) (AGC OFF，r=1，APC OFF，Y-OUT)

White Balance Range:3200 ~ 9600 oK

B.L.C Super BLC,48 zone BLC

Gain Control 0.45 /1

A.G.C AUTO (18dB max)

A.L.C. AUTO / FIX

Negative Image Select by OSD menu

Electronic Shutter AES : 1/60(1/50) ~ 1/120,000 sec. / MANUAL : 8 step

Lens 10x Optical,100x ZOOM LENS ,F1.8~3.2,f=3.8mm~38mm View Angel- H:Appr 51.2o to 5.58o; V: Appr 39.3o~4.27o

Zoom 100X (10X Optical 10X Digital)

Focusing System Auto / Manual

Positions 64 Position (Zoom，Focus)

Video Output Composite output 1.0Vp-p at 75Ω

Control Functions RS-232C (No Drive) , OSD control

Communication RS485

Addresses 0~255

Pan Range 360°Continues rotation

Tilt range 0°~60°/Sec Flip

Manual Speed Pan 0.1~60°/Sec

Manual Speed Tilt 0.1~60°/Sec Flip

Preset Speed 120°/Sec

Preset Accuracy ±0.20°

Preset Point 64 Points

Tours 6 Programable(Dwell time speed preset point)

Integrate Multi-protocol Pelco_D/P

Auto Scan Yes ( Programable speed )

Intelligent non-volatile memory for the settings and state saving Yes

Home position Yes

Continue Manual Endless

Ingress Protection IP66 Yes

Operating Temperature –55℃~55℃

Humidity 0%~80% (Non condensing)

Power Supply 24VAC 2000mA 60Hz/50Hz

Power consumption 6W

Connection multi-function adapter (BNC/ RS485/ power)
