Image Sensor 1/4" SONY

Effective Pixels NTSC:768 x 494 pixels PAL:752 x 582 pixels

Scanning System 625 lines, 50 fields/sec

Panning speed 0.1°-270°/Sec

Tilt Speed 0.1°-85°/Sec Flip

Preset Speed 400°/Sec

Tilt Angle 90°(180°)

Synchronization System Internal/ VD-Lock

Min. Illumination, normal mode 0.01 Lux(Sen-up)

Resolution 600 TVL

Signal-to-noise Ratio 48db

White Balance ATW / AWC / Fixed

Backlight Compensation Super BLC,48 BLC Areas

Auto Gain Control Auto (18db max.)

A.L.C. Auto/Fixed

Image effects Available in OSD menu

Freeze Image Function When alarm signal is triggered or can be set in OSD menu

Separating Lines On/Off, available in OSD menu (position is controlled by software)

Electronic Shutter AES : 1/50 ~ 1/10,000 sec.

Lens 27X Optical Zoom Lens,F1.5~3.8, f=3.6~98.0mm

Zoom 270X (27X Optical, 10X Digital)

Focusing System Auto/Manual

Positions 64 (Zoom, Focus)

Video Output Composite: 1.0Vp-p 75 Ohm,

Control Interface VISCA? (TTL signal level): 9.6 KB/s, 19 KB/s, 38.4 KB/s, bits: 1/2

Compression Format H.264/MPEG-4/M-JPEG

Max. Video Resolution D1, , CIF,, QCIF

Video Quality 4 levels adjustable

Frame Rate Up to 30fps

Audio Input 3.5mm stereo socket, sensitivity 1 Vrms

Audio Output 3.5mm stereo socket, sensitivity 1 Vrms

Compression Method IMA ADPCM (Pulse Code Modulation)

AUDIO Mode Two-way audio

Interface 10Base-T/100Base-TX auto-negotiation, RJ-45 socket

Support MDI/MDI-X auto crossover function

Supported Protocols HTTP, TCP / IP, UDP, RTP, RTSP,FTP, SMTP, DHCP, DNS, DDNS, NTP

Bandwidth Control Min. 64 kbps adjustable

Max. Client Limit 32 simultaneous clients

Alarm Input 1

Alarm Output 1

Event Trigger by Alarm input, Manual trigger,Motion detection and Schedule recording

Notification over Trigger alarm output, Send mail notification, Upload video to FTP, Record video to PC and Network alarm

HARTWARE RESET YES

Operating Temperature -65?C ~ + 65?C

Humidity up to 85%

Power Supply 24VAC 3A 60Hz/50Hz
