TV System PAL/NTSC

Image Sensor 1/3" Sony EXview HAD II, 960H

DSP SONY Effio-E Enhanced (CXD4140GG)

Image dimensions PAL:976 x 582 Pixels

NTSC:976 x 494Pixels

Video Output 1Vp~p Composite/75ohm (BNC connector)

Resolution 720TVL

Minimum Illumination 0.015 Lux (F2.0)

IR Controlled by a CDS sensor

IR Working Range 3.6mm, 20 Meters

IR LEDs 3.6mm, 6pcs 50°

Waterproof level IP68

Signal-to-noise Ratio over 50db

Synchronization System Internal Sync.

Backlight Compensation BLC/HLC/OFF/ON

Shuttle Auto/Manual

Gain Control Auto/Manual/OFF

F.L. (Flickerless) ON/OFF

White Balance INDOOR/OUTDOOR/ATW/ONE PUSH/AUTO

ATR ATR

Privacy Mask OFF/ON (4 Zones)

Motion Detection yes

Power Supply DC12V±10%

OSD Yes

Day & Night True Day and Night (Auto/ Day / Night / Ext. D&N)

Camera ID max 12 characters

Noise Reduction 2DNR, Y/C Level control

Gamma Correction 0.45 / 1.0 Selectable

Picture Adjustment Brightness/Contrast/Mirror/Sharpness/Gain/Hue/Saturation

Power consumption 4.5W

Operating Temperature -65°C ~ +65°C

Humidity up to 100%

Bracket 3D super-water-proof
