TV System PAL/NTSC

Image Sensor 1/3" Sony SUPER HAD II, 760H

DSP SONY Effio-E Enhanced

Image dimensions PAL:795 x 596 Pixels

NTSC:811 x 508Pixels

Video Output 1Vp~p Composite/75ohm (BNC connector)

Resolution 600TVL

Minimum Illumination 0.015 Lux (F2.0)

Mechanical IRIS Auto IRIS Control

Signal-to-noise Ratio over 50db

Synchronization System Internal/Line Lock Sync.

Backlight Compensation BLC/HLC/OFF/ON

Shuttle Auto/Manual

Gain Control Auto/Manual/OFF

F.L. (Flickerless) ON/OFF

White Balance INDOOR/OUTDOOR/ATW/ONE PUSH/AUTO

ATR ATR

Privacy Mask OFF/ON (4 Zones)

Motion Detection yes

OSD Yes

Day & Night True Day and Night (Auto)

Camera ID max 12 characters

Noise Reduction 2DNR, Y/C Level control

Gamma Correction 0.45 / 1.0 Selectable

Picture Adjustment Brightness/Contrast/Mirror/Sharpness/Gain/Hue/Saturation

Compression Format H.264/MPEG-4/M-JPEG

Max. Video Resolution D1, , CIF,, QCIF

Video Quality 4 levels adjustable

Audio I/O 1/1

Operation Mode Two-way audio

Interface 10Base-T/100Base-TX auto-negotiation, RJ-45 socket ; Support MDI/MDI-X auto crossover function

Supported Protocols HTTP, TCP/IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS, DDNS, NTP, uPnP

RS-485 Yes

Alarm Input/Output 1/1

Event Triggered by Alarm input, Manual trigger,

Notification over Trigger alarm output, Send mail notification, Upload video to FTP,Record video to SD card, Send HTTP notifi cation and Network alarm

SD Card SD/SDHC memory card slot (card is not included)

Hardware Reset Button Yes

Power Source AC24V/DC12V & PoE

PoE Optional (PoE 802.3af)

Power Consumption 5W max. (12VDC)
