TV System PAL/NTSC

Image Sensor 1/3" Sony EXview HAD II, 960H

DSP SONY Effio-E Enhanced

Image dimensions PAL:976 x 582 Pixels

NTSC:976 x 494Pixels

Video Output 1Vp~p Composite/75ohm (BNC connector)

Resolution 720TVL

Minimum Illumination 0.015 Lux (F2.0)

IR Controlled by a CDS sensor

IR Working Range 3.6mm, 40 Meters

6.0mm, 40 Meters

2.8~10mm, 60 Meters

9~22mm, 100 Meters

6~50mm, 160 Meters

Mechanical IRIS Auto IRIS Control

Waterproof level IP68

Signal-to-noise Ratio over 50db

Synchronization System Internal

White Balance AUTO

Temperature Sensor build in temperature sensor

Heater YES

Compression Format H.264/MPEG-4/M-JPEG

Max. Video Resolution D1, CIF, QCIF

Video Quality 4 levels adjustable

Frame Rate Up to 30fps

Compression Method IMA ADPCM (Pulse Code Modulation)

Interface 10Base-T/100Base-TX auto-negotiation, RJ-45 socket

Support MDI/MDI-X auto crossover function

Supported Protocols HTTP, TCP / IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS, DDNS, NTP

Bandwidth Control Min. 64 kbps adjustable

Max. Client Limit 32 simultaneous clients

Alarm Input 1 x input for dry contacts, Normal Open / Normal Closed adjustable

Alarm Output 1 x dry relay contact, Normal Open / Normal Closed adjustable, 70 VDC / 200 mA max

Event Trigger by Alarm input, Manual trigger, Motion detection and Schedule recording

Notification over Trigger alarm output, Send mail notification, Upload video to FTP, Record video to PC and Network alarm

Bullet-proof, Antivandal YES

Power Source DC12V & PoE

PoE Optional (PoE 802.3af)

Power Consumption 10W max. (12VDC)

Bracket 3D super-water-proof
