Camera Type 2MP Full HD Network Dome Camera

Pickup Device 1/3" Progressive Scan CMOS

Pixel Effective 1600x1200@15fps, 1280x720 @ 30fps

Sensitivity 0.1 Lux / F=1.2 (IR Off)/0 Lux (IR On)

Day & Night True Day/Night with IR cut filter

Electronic Shutter Rolling

IR IR LEDs+Mechanical IR cut filter

Controlled by a CDS sensor

IR Working Range 4.3mm, 40 Meters

2.8-10mm 60Meters

Compression Format H.264/MPEG-4/M-JPEG

Video Quality 4 levels adjustable

Interface 10Base-T/100Base-TX auto-negotiation, RJ-45 socket ;

Support MDI/MDI-X auto crossover function

Supported Protocols HTTP, TCP/IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS, DDNS, NTP, uPnP

Alarm Input/Output 1/1

Event Triggered by Alarm input, Manual trigger,

Notification over Trigger alarm output, Send mail notification, Upload video to FTP,

Send HTTP notifi cation and Network alarm

Bullet-proof, Antivandal YES

Power Source AC24V/DC12V & PoE

PoE Optional (PoE 802.3af)

Power Consumption 10W max. (12VDC)

Bracket 3D super-water-proof
