Supported IEEE1394 connector for up to 8 HDDS or external RAID 1~5

Loop-Through up to 255 DVRs

Smart search & playback

Digital zoom X2, X4

Intelligent search

Multiplex System : Synchronic record, Live playback, backup, control. Remote monitoring

Auto power on for system recovey

Support 2 X HD, SATA interface, 2TB is available

Additional function POS/PTZ/GPS control.

Specifications

Compression H.264 Compression

Recording Speed NTSC: 480 fps, PAL 400 fps

Hard Disk 2 x HD, SATA interface, 2 TB is available (1 x extension SATA connector) IEEE1394 connector for up to 8 HDDs or external RAID:1~5

Video In BNC x 16 ch

Audio In RCA x 4 ch

Video Output BNC/D-SUB VGA (15-pin) S-video

Audio Out RCA x 1

D. Zoom 2X, 4X

Alarm Functions Buzzer, e-mail, screen msg, mobile device (triggered by sensor input, Video loss & Montion)

Dimensions 430 x 330 x 88 mm

Power Supply 12V DC (80W Max)

Operating Function IR controller and Graphic OSD, IE Brower Remote monitoring supported (up to 8 users). cellphone AP, PTZ connector, POS, GPS, watermark, pre-alarm, hardware type watch dog, motion detection. Auto power on for System recovery, 24 language supported.
