TV System PAL/NTSC

DSP 1/3" SONY Super HAD CCD, SONY DSP HQ1

Image dimensions NTSC:811 x 508Pixels PAL:795 x 596 Pixels

Video Output 1Vp~p Composite/75ohm (BNC connector)

Resolution 600TVL

Minimum Illumination 0 Lux (IR LEDs+Mechanical IR cut filter)

Controlled by a CDS sensor

IR Working Range Indoor: 30-40 Meters, Outdoor: 20-30 Meters

IR LEDs 15 pcs

Waterproof level IP67

Signal-to-noise Ratio over 50db

Synchronization System Internal

Backlight Compensation ON / OFF switch

Auto Gain Control ON / OFF switch

F.L. (Flickerless) ON / OFF switch

White Balance AWB

Lens f2.9mm~10mm/F1.2 D/N lens/94.6~28.8?standard)

Power Supply 12V DC(Standard)

Lead content Yes

Power consumption 4.5W

Operating Temperature -55°C ~ +50°C

Storage Temperature -65°C ~ +60°C

Humidity up to 100%

Dimensions 108 x 66 mm

Weight 490g
