●10x Digital Zoom

●Variable focus and iris speed

●Compatible with Pelco speed control +/-12V ~ +/- 6V

Specifications

Water Resistance IP66/Heater built in:6°C on/14°C off

TV System NTSC/PAL

Image Sensor 1/4" SONY Super HAD CCD

Resolution 520 TVL

Image dimensions NTSC 768 x 494 Pixel; PAL 795 x 596 pixels

Compression MPEG-4 Hardward Compression

Image Frame Rate NTSC:30fps@720 x 479; PAL:25fps@720 x 576

Maximum Resolution D1/2CIF/CIF/QCIF

Network 10/100 base- T for LAN/WAN

Protocols TCP/IP,HTTP,DDNS,PPPoE,ARP.TCP,UTP,RTP,DHCP

Manual Speed Pan 0.1~300°/Sec

Manual Speed Tilt 0.1~120°/Sec

Preset Speed 400°/Sec Intelligent Auto-tracking

Operation Backup Ai software,IE browser OSD control,128 present points,Auto Scan Function,6Programmable tours,Motion detection, Recording format in AVI,Multi-language supported

Minimum Illumination 0 Lux(F1.8,5600°K)/Day&Night mode

Lens 27 x Optical,270 x Zoom,F1.4~3.8,f=3.6~98.0mm

Integrate multi-protocol Pelco D/P

Communication RS485

Operating Temperature -55°C~+60°C

Power Supply 24 VAC 2 A 60Hz/50Hz
