A-MTK “Smart focus” stands for following functions: Remote zoom/focus, P-iris, day and night auto focus. Clients no need to drive car to the site for lens adjustment. With smart focus IP camera, just sit in front of PC and remotely control the lens wide, tele, auto- focus. P-iris is to control the stepping motors and have the iris control precisely, and remotely. Smart focus makes installation and maintenance easier and cost-saving. It is a brilliant function for project planning.
• 2Mega@60fps high frame rate
• 2Mega@30fps True WDR mode selectable
• H.264 and MJPEG simultaneously
• IVA functions built-in Built in IR LED and ICR for day & night surveillance
• Motorized and P-iris lens
• Event trigger: DI, audio detection, camera tampering, object detection, face detection, cross line
Camera module
Image Device Sony Exmor 2.41 Mega-pixel image sensor, 1/2.8“ size
Effective Pixels 1920x1080 pixels
Lens 3-10.5mm remote motorized zoom Lens
Focus Auto Focus
IRIS type P-iris
ICR type Mechanical
IR LED 24pcs IR distance Support auto/ manual/ schedule IR LED on, off
Video
Video Encoder H.264 and MJPEG simultaneously
Video Profile Dual stream for WDR mode (Resolution Adjustable)
Wide Dynamic Range More than 100dB (double scan sensor)
Frame Rate Up to 60fps for 60fps mode
Up to 30fps for WDR mode
Exposure Control Auto / Auto Indoor / Manual Exposure
(Manual mode : 1/2~1/10,000 seconds)
Photometry Method : Average / Center / Spot / BLC / FLC
Image Setting AE, AWB
3D Noise reduction
Ture WDR
Exposure value, Color, Hue , Brightness, Contrast, Sharpness,
Mirror/Flip
DIS
Privacy masks
Pixel count
On Screen Display Text, time and date overlay
Editable OSD (bitmap format)
Area of Interest Higher quality in AOI area
Streaming Simultaneously dual streaming
Simultaneously dual streaming
M-JPEG streaming over HTTP (server push)
M-JPEG streaming over HTTP (server push)
Constant and variable bit rate (H.264)
Audio
Audio Encoder RTSP: G.711 64kbps, G.726 32kbps, AAC (option, by request)
Audio Streaming One-way or two-way
Microphone External microphone
Audio Output Adjustable audio output gain
Network
Supported Protocols IPv6, IPv4, TCP, UDP, HTTP, HTTPS, SMTP, FTP, NTP, DNS, DDNS, DHCP, DIPS, ARP, Bonjour, UPnP, RTSP, RTP, RTCP, IGMP, PPPoE, 3GPP, Samba, ICMP, SNMP , QoS
Security Password protection, IP address filtering, HTTPS encrypted data transmission, user access log
Users 20 simultaneous unicast users
Ethernet 10/100/1000M auto negotiation
System Integration
SDK ONVIF
Open API for software integration
Event Detection External input (DI)
IVA trigger : Object Detection (Missing object), Camera tampering, Audio detection, Face Detection, Cross Line Detection (tripwire)
Object Detection Detection with Entrance , Desertion or Theft options
Audio Detection Audio level 0-100
Camera Tampering Camera dis-focus / move direction / mask
Cross Line User defined two cross line , and user defined entrance direction
Alarm Events File upload via FTP or email
File upload via Samba to NAS
Notification via email, HTTP, and TCP
External output activation
Audio alerting output
Push notify to smart phone apps
Video Buffer Pre- and post- alarm buffering
General
RAM 384MB
ROM 256MB
Power Supply 12V DC external power adapter
PoE IEEE 802.3af class 3
Power Consumption Max. 10W (12V DC in)
Connectors RJ-45 10Base-T/100Base-TX/1000Base-T
12VDC power jack
1 alarm input and 1 output
RS485
Indication LED Green and orange LEDs
Operating Temperature -10°C to 50°C
Operating Humidity 20% ~ 80% (non-condensing)
Viewing System
OS Windows XP, Vista, 7, 8 , 8.1
Browser IE 7.0 or later, Firefox 2.0 or later, Safari , Google Chrome
Video Player VLC, Quick Time, Real Player, Core Player
Software
Search & Installation IP Wizard II
Easy DDNS DIPS
Bundled NVR Program * 64ch. SecuGuard?
* 64ch. multi-channel supports Tri-decoder
* 16ch. video playback (simultaneously)
* Smart & scrollable digital zoom. Snapshot and edit
* Motion, DI, Scheduler recording
* Fast rewind and forward (MPEG4, H.264, MJPEG rewind)
* 32x24 motion detection grids
* Smart search (by time, by motion )
* E-MAP
* Event schedule setting
* Remote service
* Camera tampering
Bundle Mobile Phone APPS SecuAngel (Android) and iVanguard (iOS)
