Image Device |
Sony 1/1.8” Exmor™ 6 Mega-pixel image sensor |
Effective Pixels |
2592x1944 |
Lens |
C/ CS mount, support DC and P-iris lens |
Lens Adjustment |
Remote back focus adjustment |
Min. Illumination |
Color: 0.02 lux @F1.2 (AGC on)
B/W: 0.005 lux @F1.2 (AGC on) |
Day & Night |
TDN (Mechanical ICR) |
|
Video Encoder |
H.265(HEVC), H.264 (base line, main-profile, and hi-profile) and MJPEG simultaneously |
Video Profile |
4 streams simultaneously for 5M mode
4 streams simultaneously for 1080p mode |
Frame Rate |
Up to 25 / 30fps in all resolutions for 5MP mode
Up to 50/ 60fps in all resolution for 1080p mode |
Region of Interest |
Max. 4 ROI @ 5M pixels mode. Editable range
Max. 4 ROI @ 1080p mode. Editable range |
Exposure Control |
Auto / Auto Indoor / Manual Exposure
(Manual mode : 1/2~1/10,000 seconds)
BLC On/Off
Enhanced WDR |
Image Setting |
AE, AWB
3D Noise reduction
Color, brightness, sharpness, contrast, Hue
Image Mirror/Flip, 90o rotation
Privacy Masks
DIS
Pixel Count
Anti-False Color
Defog |
On Screen Display |
Text, time and date overlay
Editable OSD |
Streaming |
Simultaneously multi-streaming
Streaming over UDP, TCP, HTTP, or HTTPS
M-JPEG streaming over HTTP (server push)
Controllable frame rate and bandwidth
Constant and variable bit rate
ROI
AOI (Higher Quality in AOI area) |
|
Audio Encoder |
RTSP: G.711 64kbps, G.726 32kbps, AAC (optional, by request) |
Audio Streaming |
One-way or two-way |
Microphone |
External microphone input |
Audio Output |
Adjustable audio output gain value |
|
Supported Protocols |
IPv4, IPv6, TCP, UDP, HTTP, HTTPS, SMTP, FTP, NTP, DNS, DDNS, DHCP, DIPS, ARP, Bonjour, UPnP, RTSP, RTP, RTCP, IGMP, PPPoE, 3GPP, Samba, ICMP, SNMP, QoS, CoS, 802.1x, iSCSI |
Security |
Password protection, IP address filtering, HTTPS encrypted data transmission, user access log |
Users |
20 simultaneous unicast users |
Ethernet |
10Base-T/100Base-TX auto negotiation |
|
Application Programming Interface |
ONVIF compatible
Open API for software integration
SDK |
Alarm Triggers |
Video motion detection
Camera Tampering
Audio Detection
Digital input
Network Disconnect |
Motion Detection |
10-zone video motion detection with included or excluded options |
Alarm Events |
File upload via FTP or email
File upload via Samba to NAS
Notification via email, HTTP, and TCP
External output activation
Audio alerting output
Push notification to smart phone APP(AMTK)
ICR On/Off |
|
Power Supply |
DC12V |
PoE |
IEEE 802.3af class 3 |
Power Consumption |
7W (12VDC) |
Connectors |
RJ-45 10Base-T/100Base-TX
12VDC
1 alarm input and 1 output
RS485
Audio out
External Audio input
Composited video out
Factory default reset
Micro SD card slot |
Indication LED |
Indication LED |
Operating Temperature |
-10°C to 50°C |
Operating Humidity |
10% ~ 90% (non-condensing) |
Dimension |
125 mm x 58 mm x 62 mm |
Certification |
CE, FCC, RoHS |
|
OS |
Windows® 7, 8 |
Browser |
IE 9.0 or later, Mozilla Firefox, Chrome, Safari |
Smart phone |
Android™, iPhone™ |
Video Player |
VLC, Quick Time, Real Player, Core Player |
|
Search & Installation |
IP Wizard II |
Easy DDNS |
DIPS™ |
Bundled NVR Program |
64ch. SecuGuard™
* 64ch. multi-channel supports Tri-decoder
* 16ch. video playback (simultaneously)
* Smart & scrollable digital zoom. Snapshot and edit
* Motion, DI, Scheduler recording
* Fast rewind and forward (MPEG4, H.264, MJPEG rewind)
* 32x24 motion detection grids
* Smart search (by time, by motion)
* E-MAP
* Event schedule setting
* Remote service
* Camera tampering |
Bundle Mobile Phone APPS |
SecuAngel (Android) and iVanguard (iOS) |
