OTS network switch enhance transmission system for Royal Oman Police Station

One of the high-tech Police force in the world, the Royal Oman Police has replaced OT Systems' transmission systems in police station. The faster and more stable fiber optical switch with video analytic technology helps the Police force efficiency.

OT Systems’ industrial managed switch IET8242MPpH-S-DR with Strong 6KV Surge protection PoE function, support 20km optical distance and the embedded software “Surveillance Device Management” is a cutting-edge solution for the operator at the transmission monitoring systems, providing real-time monitoring and troubleshooting.

Inside the police station, the application with our industrial IP CCTV switch ( ET4222Pp-S-DR, ET8122PpH-S-DR ) connects with the IP cameras to guard the police cells security.

Applications of our full portfolio managed, self-configured / smart and unmanaged Ethernet switches secure and boost IP-communication networks in police station parking area, sensor devices.

Solution products

1. IET8242MPpH-S-DR

Managed Ethernet switches

Features:

• 8 10/100/1000Base-T + 4 100/1000Base-X SFP
• Support IEEE802.3at PoE+(30W per port)
• RJ45 Port Supports 10/100/1000Mbps-Full/Half-duplex, Auto-negotiation, Auto MDI/MDIX
• SFP Slot Supports 100/1000Mbps
• Supports IGMP v1/v2/v3, up to 1024 groups
• Supports IEEE1588v2 PTP
• Supports IEEE802.1Q VLAN, SNMP v1/v2c/v3
• Web GUI, Serial Console, CLI Command configuration
• Network Redundancy support: G.8032 ERPS, RSTP, MSTP
• 6KV surge protected
• Redundant DC Power Inputs
• -40°C to 75°C (-40°F to 167°F) operating temperature
• Embedded Surveillance Device Management

2. ET4222Pp Series

Self-configured Ethernet switches

Feature:

• Automatically support IGMP (Multicasting)
• Supports 10/100/1000Mbps-Full/Half-duplex, Auto-negotiation, Auto MDI/MDI-X
• Supports external 1000Base SFP
• Supports Daisy-Chain connection
• Supports IEEE 802.3at PoE+ (30W per port)
• Supports Light Hardware IGMP V1, V2, V3
• Supports Broadcast Storm Control
• Supports Relay output for power failure
• 1M bits frame buffer memory
• Supports 9K Bytes Jumbo Frame
• Supports Energy Efficient Ethernet IEEE802.3az
• Redundant Power Inputs
• Supports Wall-mount and DIN-Rail installation
• Environmentally hardened -40°C to 75°C ( -40°F to 167°F) operating temperature

3. ET8122PpH-S-DR

Unmanaged Ethernet switches

Feature:

• 8 10/100Base-TX + 2 10/100/1000Base-TX/SFP Combo with PoE+ / PSE
• Support IEEE802.3at PoE+ (30W per port)
• RJ45 Port Supports 10/100Mbps-Full/Half-duplex, Auto-negotiation, Auto MDI/MDIX
• Combo RJ45 Port Supports 10/100/1000Mbps- Full/Half-duplex, Auto-negotiation, Auto MDI/MDIX
• Supports external SFP
• Supports 802.3x Flow control
• Support 8K MAC addresses
• 1M bits frame buffer memory
• Supports Relay output for Power and Port failure
• Redundant Power Inputs
• Supports DIN-Rail and Wall-mount installation
• Environmentally hardened -40°C to 75°C (-40°F to 167°F) operating temperature
