The burglar MMS alarm system is a brand new Hi-Tech product in the wireless communication era, it has integrated 2G & 3G mobile transmission technology and IR image monitoring and thermo detection such kinds of security technologies.

It has breaking through the limitation of conventional CCTV system that transmitting by hardwire cable/modem which is difficult to install and has higher cost and limited by the installation environment, it also has problem of easy to be invaded.

This product combines the future mobile user's needs to let any mobile phone user (must have GPRS/MMS/SMS function) can use their mobile's AV and mailbox function to back up the image information (to avoid the destroy of evidences), can real-time receives the alarm messages from any remote location by the AV Monitor devices or monitoring the real-time voice and image from the site for immediate identification. It meets various demands from sectors of household, office, factory, stores….etc.

1-2 Main functions:

*IR thermo image monitoring and detection for moving objects, the double detection technology can eliminate the false alarm caused by environmental reasons.

*It has real-time mobile AV alarm and e-mail video image back-up receiving model.

*You can monitor the site by mobile phone at any time.

*You can use mobile to monitor the voice at the *Easy operate with a wireless remote control device by simple mobile instructions.

*You can setting if the siren and beacon device to be activated when alarm happen.

*Under emergency situation EMSD key can silently inform any designated users.

*Able to add external siren to enhance the sound to frighten the burglar.

*With build-in back up battery, device can be still operating during power failure.

*Able to add external 4 wired detectors and 9 wireless detectors.

*Add door bell function, very convenient and practical.

*With IR night vision camera, it provides full time 24 hours day and night monitoring function.

Package List：

* Console x 1 * Antenna x 1

* Power adaptor x 1

* Remote Con. x 2

* Rechargeable battery x 1 * Instruction Manual x 1

* Universal mounting kit x 1 * Warranty card x

11-4 Options：

* Enhanced antenna

* Remote con.(maximum number is 10 units)

* Alarm extension unit（Camera unit or Detection unit）

Reserved function (future version)

* Video line (digital signal serial port) Reserved function (future version)

Main Technical Parameters：

* PIC Format JPEG

* Resolution 320X240 /408 X320 pixels

* Camera View Angle Horizontal 60o / Vertical 60o

* Effective Range < 20 meters

* Remote Control Distance < 30 meters

* Backup Battery < 72 hrs (depends on battery capacity)

* Working Temperature 0-50oC (32-122oF)

* Relative Humidity 10-90%, non-condense
