Key Specifications
Model YS-130NO/NC

Product Name: Standard-type Electric Strike

Face plate:150Lx39.5Wx28H(mm)

Standard Structure: Stainless Steel

Dual Voltage:DC12V

Current Draw:130NO/450mA!130NC/200mA

Fail Safe: Locked when energized (YS130NC)

Fail Secure: Locked when unenergized (YS130NO)

Safety function:Built-out voltage spike suppressor

Performance Testing:one hundred thousand times aging test

Opening Mode:90 degree swinging door

Suitable For:Wooden Door, Metal Door, Fireproof Door.

Authority Certification:CE & MA approved

Quality Guarantee:For two years(except that man-made and Force Majeure)

Net Weight:0.35kg

Standard packing:70pcs/box
