Telling industrial IP cams apart

Editor / Provider: Basler | Updated: 5/23/2013 | Article type: Tech Corner

Industrial (machine vision) cameras are used for a variety of industrial quality assurance and process control applications, according to a recent white paper written by Bjorn Webe, PM of IP Cameras at Basler. They give machines the power of sight, which is a major enabling factor for quality assurance in production processes. What many industrial camera users don't know: network cameras, also known as IP cameras, are also an effective tool for monitoring production processes.

Typical Characteristics of a Network Camera
With network cameras, the reproduced images are inherently optimized for human viewing as well as for long-term storage of the data. To ensure this last aspect, the image data is compressed while still in the camera. This is beneficial on the one hand because it cuts down on the amount of storage space needed to archive the videos. On the other hand it also reduces the necessary bandwidth overhead for video transmission and allows the cameras to be used even in budget-minded networks built around low levels of capacity. For this reason various cameras can run parallel to one another.

Network cameras compress the image data within the camera.
Advantage: requires less bandwidth and less storage space.
Network cameras have another major benefit: uncomplicated operation. Once the IP camera is connected to a network, any computer on that network can then access its images by entering the camera's IP address into a browser. This makes it easy for an electrician to mount and activate the cameras. While industrial cameras offer a very broad spectrum of configurations and are often more complicated, network cameras are relatively simple, with a viewing angle and focus factor all that's needed for immediate use.

Network cameras can be used effectively anywhere where production processes or movement sequences (of any kind) are to be filmed and monitored by a human observer. They are especially well suited for applications that require good image quality despite changing light, weather or temperature conditions. IP cameras are especially crucial if the image data is to be stored.

Ideal Uses for Network Cameras
Given their technical properties, network cameras are the perfect choice for use in monitoring tasks. These range from classical video surveillance to anti-theft and anti-vandalism applications, as well as controlling of production processes and workflows and traffic monitoring. IP cameras are also well suited for remote control of machinery, cars and robots. The different characteristics are decisive for achieving optimal results with the different applications:

• For video surveillance it is especially important that the cameras deliver good images despite changeable or poor lighting conditions. Casinos, for example, are typically set up with dim lighting yet have strict quality standards to ensure safety.
• Cameras for traffic monitoring and video surveillance are frequently subjected to outdoor conditions, which means that the cameras must be able to adjust automatically for a wide range of light conditions. They must also be robust enough to handle both moisture and large fluctuations in temperature.
• In the surveillance field it's a benefit to have multiple network cameras running simultaneously. An observer in a central location can use the cameras to gain an overview of the different areas — from building and traffic management to monitoring of production workflows, such as for the printing and courier industries.
• Network cameras are especially well suited for use in the logistics and transport fields, since they are easy to integrate into existing video management systems.
• No local PC is required to examine the image data from a network camera, allowing them to be used in difficult-to-access spots (such as tunnels), locations subjected to extreme conditions (heat, cold, hazards), or far away from the control center (traffic hubs, etc.).. Because network cameras compress their image data for better storage, they are an excellent choice for a wide variety of areas where “documented proof” must be stored for extended periods. This is particularly true for traffic violation cameras, events such as soccer matches and surveillance videos.

Gainspan unveils development kit for wireless surveillance

Editor / Provider: GainSpan | Updated: 5/23/2013 | Article type: Component

GainSpan Corporation, a supplier in ultra-low power Wi-Fi connectivity for the Internet of Things, introduced a complete reference design for wireless video streaming applications such as remote security/surveillance cameras, car back-up cameras and video baby monitors. The new Video Application Development Kit (ADK) speeds and simplifies design and integration of video streaming services into end products based on GainSpan Wi-Fi modules.

GainSpan's Video ADK includes hardware and software that help reduce the time needed to develop products that deliver live video over Wi-Fi. With the development kit, users can stream the video feed from a Wi-Fi enabled camera to an iOS or Android based smartphone.

Included in the Video ADK is a video application board, complete hardware design package and software suite with reference source code for the embedded video application, and iOS and Android based mobile applications. An Application Evaluation Kit (AEK) is also available that provides a binary version of the software and video mobile application.

The Video application board features the GainSpan GS1011M Wi-Fi module that communicates with an H.264 video compression chip (VGA resolution at 30 frames per second) over the SPI bus, a VGA camera and imaging sensor module, a motion detector, a single snapshot trigger button, a WPS/Provisioning button for easy set-up of the wireless network and mode indicator LEDs. The GainSpan embedded software running on the Wi-Fi module offers complete Wi-Fi functionality including the networking stack and services and wireless security. It supports mDNS/DNS-SD based device and service discovery that allows users to automatically discover and connect to the embedded video profile. In addition, it includes provisioning software that allows configuration of the Wi-Fi module in Limited AP or Client modes, and supports over-the-air firmware upgrades.

Offering flexibility of design and customization, the new kit provides hardware and software building blocks that provide a starting point for product development while allowing the developer to add application software and services, and customize the end product's user interface. With the reference source code included in the kit, customers can rapidly build custom features suited to their video applications.

"IP video surveillance cameras will soon represent over 50% of the video surveillance market and the demand for Wi-Fi based cameras has increased significantly due to ease of installation. With our Video ADK we've made it simple for customers to develop battery operated or line powered Wi-Fi cameras that can be activated through motion control" said Bernard Aboussouan , vice president of marketing at GainSpan. "This is the latest ADK featuring a complete end application that we've brought to market and, like our other ADKs, is designed to help customers get their products and services to market quickly and reliably."

In addition to the new Video ADK, GainSpan offers six other application development kits: a Smartplug ADK, Audio ADK, Temperature and Light Sensors ADK, Renesas Wi-Fi Sensor ADK, and functional ADKs such as Provisioning and Over-the-Air Firmware Update.

Mobotix releases three new 5-megapixel models

Editor / Provider: Mobotix | Updated: 5/23/2013 | Article type: Security 50

Mobotix has launched three new camera models with higher frame rate, better light sensitivity, better zoom capability utilizing 5 Megapixel technology.

The new camera models S15, D15 and V15 are developed from the already successful predecessor series. By using 5 Megapixel sensors in these new camera models, the users will be able to experience clear advantages. "The most visible changes that we have made for the users are that they will experience a clearly better light sensitivity in low light conditions or at night," says Dr. Ralf Hinkel, founder of Mobotix. "The light sensitivity of the overall image quality is up to four times better, which enhances the overall image quality in for instance bad weather conditions and in the dark."

The maximum QXGA resolution is therefore more than 2.5 times higher than full HD. Another major advantage is that the new sensor technology in combination with preprocessing the image data directly in the camera delivers a video stream frame rate of up to 30 frames per second. An increased zoom capability of the S15, D15 and V15 enhances the possibilities even further. "We have increased the zoom option in color by 27% by using the new sensor technology, and by more than 200% in black-and-white," continued Hinkel. This results in more detailed images and allows for the camera to be positioned further away from the monitored areas. This allows users to benefit from increased flexibility when it comes to planning and installation.

The new S15, D15 and V15 camera models are equipped with the new, unique MxActivitySensor for camera-integrated video motion analysis. Once configured, the free-of-charge software can distinguish between relevant and irrelevant movements, drastically reducing the number of false alarms.

The new models equipped with 5 Megapixel sensors are all available as of immediately over authorized MOBOTIX distributors and partners.

Asia Update: Keda bringing vertical solutions to global security theater

Editor / Provider: Hayden Hsu, asmag.com | Updated: 5/22/2013 | Article type: Hot Topics

There is no better “test bed” than China. With its land mass, population and security focus and budget, the country is a perfect breeding ground for security solution developers and providers, especially with large-scale networked systems. Here is one success story in the making.

Headquartered in Suzhou, China as a subsidiary of Keda Communications, Keda Technology has come a long way since its establishment in 1995 as a telecommunication and video conferencing system specialist and 2005 IPO in Singapore. With its 2012 revenue exceeding US$160 million and work force of 3,000+, the company is chomping at the bit to take its fine-tuned vertical solutions abroad, for government and MNC users that are looking for tried-and-tested quality HD surveillance video to tackle their security and management headaches.

Thanks to its decade-long cultivation and experience between 1995 and 2004, Keda had honed its network communication capability through its countless video conferencing projects at government agencies and business entities across the country. According to John Xue, Executive Director for Keda Technology, it was also during that period that the company realized the significance of easy-to-use software interfaces and seamless technical support. “Owing to our earlier partnership with Philips, we have exceled at hardware manufacturing, video imaging processing, and frame/bit rate control and management. But it was through these domestic but nationwide projects that we learned to be especially mindful of the unique implementation and day-to-day requirements of system integrators and government/enterprise end users.”

After the “Safe City” initiative swept across and started to take root in China in 2007/2008, Keda got to demonstrate how its intelligent, interconnected IP cameras, NVRs and management platforms could help end users better react to constantly evolving site conditions at many more multisite projects. “We were fortunate to be given the many opportunities to evolve as well, to grow to be application-specific in how analytics and automated alerts can be deployed in various environments,” Xue shared. To date, 14 to 16 percent of Keda's annual turnover is earmarked for R&D endeavors.

Open Arms
To continue to drive innovation and scale new heights, Keda is eyeing the cloud and global market. “We have an open-door, open-arms policy. With cloud-based applications growing exponentially, we want to collaborate with as many technology partners as possible because we can't do it all alone. We will also continue to work on optimizing image processing and bandwidth allocation management so that better and sooner preventive and preemptive measures can be taken.”

Keda is now active throughout Asia (from Japan and Korea all the way to Southeast Asia), the Middle East, Eastern Europe and Africa, and continues to look for capable and compatible distribution partners. “The security market is highly dynamic yet with a much longer selling cycle, so there is a lot more unpredictability. We are taking the time to groom our partners, grow our development and distribution networks, and hone our branding and sales management efforts,” Xue expressed.

Keda is ready and open for business — are you?

UK boutique hotel operator rolls out standardized surveillance at 14 locations

Editor / Provider: Samsung Techwin | Updated: 5/21/2013 | Article type: Residential & Consumer

Radisson Blu Edwardian Hotels, a luxury hotel franchise in UK with 14 distinctive hotels ranging from bijou boutique to large-scale luxury, located in London, Heathrow, Guildford and Manchester, recently upgraded its more than 700-camera analog video surveillance system with a new standardized analog system consisting of Samsung Techwin cameras and 40 DVRs. The hotel has entered a long term single source supply relationship agreement with Samsung, to equip all its hotels with Samsung video surveillance solution.

The safety of guests and staff has always been the hotel's top priority and Radisson has never hesitated to invest in the latest video surveillance technology. However, this resulted in many different types of cameras and recording devices from various manufacturers being deployed across its hotels. Mohamed Elsebahy, Group CCTV Manager, held a strong opinion that significant operational advantages could be achieved by a process of standardization. The hotel researched whether it would be possible to single source all the components of a video surveillance system from one manufacturer, said Elesbahy.

The starting point for the detailed research as to what products would best match Radisson's demanding requirements was the video recording solution. Although images from the 700 plus domes installed across the 14 hotels can be viewed live at control rooms located at Heathrow and London, the key objective has always been to record activity captured by the cameras so that any incidents or suspicious activity can be investigated, and if appropriate, video evidence can be retrieved and passed onto the police for prosecution purposes.

Samsung's DVR, which can simultaneously record real time images across all of its 16 channels at 4CIF was chosen after a four month trial, however, the hotel required certain adjustments. “We identified from our operational perspective some shortcomings in the list of features available in the VMS that is provided with the DVR,” said Nick Kalsi, Technology Consultant of the hotel. “What we felt was missing was the ability to name the DVRs, make brightness adjustments and also to manage the printing of images via the software.” Samsung customized the DVRs to meet the hotel's specifications.

Images from the 700 domes are recorded at different frame rates depending on the type and level of activity anticipated at each camera location and all of the images are stored for 30 days. So far 200 units have been replaced with either IR internal domes, WDR indoor domes or with vandal-resistant external domes. The remaining 500 units will be replaced in the near future as part of a phased upgrade program.

"Working closely with a single manufacturer has proved to be a great success as they have been able to provide objective advice on the correct camera model for every location,” said Mohamed Elsebahy. Local police officers have also commented that the video surveillance system at Heathrow hotel is one of the most reliable of many hotels on the A4 strip. Radisson is in the process of testing Samsung's NVRs with a view to migrating from an analog based system to a networked IP solution.

Idis launches bundled VMS

Editor / Provider: Idis | Updated: 5/21/2013 | Article type: Security 50

Idis has announced, during Ifsec International, that it will bundle Idis Center VMS at no extra cost, as part of its DirectIP HD video surveillance solutions. The bundled offering provides customers with a complete VMS to install, configure, integrate and operate DirectIP solutions without licensing fees or complexity.

“VMS has too often become synonymous with cost and complexity within the industry. By bundling IdisCenter we are offering customers a true one-stop-shop solution without the need for expert IT or network skills, nor the cost involved in buying and renewing software licences,” noted Brian Song, MD of Idis.

Idis Center provides customers with plug-and-play management software to install and operate network cameras, NVRs and servers. Through an intuitive user interface very similar to that of traditional analogue systems, users are able to view live video and playback simultaneously. Idis Center further provides real-time event notification to improve incident response times, as well as a panic recording feature. The system provides easy and fast installation and configuration of up to 1024 devices and enables hassle-free maintenance via remote software upgrades.

Song commented, “This further builds on the Idis commitment to deliver simple, cost effective end-to-end HD video surveillance through our DirectIP solutions, all built on the quality and performance Idis customers the world over have come to expect.”

Milestone signs on UK distributor Oprema

Editor / Provider: Oprema | Updated: 5/21/2013 | Article type: Security 50

Oprema have secured the rights to distribute Milestone Systems open platform IP VMS as part of Milestone's strategic decision to work with specialist IP security suppliers in the UK. Milestone XProtect software has been keenly welcomed by Oprema's existing client base, and it is anticipated that this collaboration will further new business interest for the Cardiff based security distributor.

Oprema have been championing IP technology for a number of years, and it is for this reason that Milestone has added them to its exclusive UK distributor list. Oprema will offer not only the full suite of software products but will be hosting Milestone Certified and Milestone Professional training courses as the only authorised independent Milestone Systems training center in the UK. The training courses will cater for first time users through to experienced users looking to broaden their knowledge. The training will also include configuration, set up and use of supported hardware.

Milestone was Oprema's desired partner for IP video surveillance software because it is scalable and easy to use. Customers will be able to purchase software licences only or as part of a custom built server solution offered by Oprema.

Oprema's MD Matthew Epps commented, “We are delighted to be offering such a high-end and well regarded product as Milestone XProtect with our IP solutions. The agreement is a significant one for us, and shows how much of an impact Oprema are making in the market place, in moving the trade towards IP by offering cost effective packages as well as high-end solutions to suit any budget and application. Milestone fits in perfectly with its complete range of software options from XProtect Go right through to XProtect Corporate.”

Glenn Fletcher, Country Manager UK & Ireland for Milestone, adds: “Milestone Systems are happy to have Oprema on board as a new UK distributor. They will be able to help with technical training and server designs, leveraging the Microsoft and IP skills that they already have in house. Oprema are also our gateway into Wales as a distributor, which was another key reason for selecting them to be part of our expanding Milestone UK team of partners. We aim to grow together in the coming years as the Milestone open platform VMS approach continues to be embraced in the UK.”

Since the agreement was signed in January 2013, Oprema have successfully won a number of projects with Milestone VMS pre-loaded on Oprema's in-house manufactured servers. This is ensuring that the partnership is a winning combination for UK installers by offering a cost-effective solution with the highest level technology available on the market today.

Wisconsin electronic parts manufacturer eyes remote security management as marketing and profit-generating tools

Editor / Provider: Matrix Systems | Updated: 5/20/2013 | Article type: Commercial Markets

Norstan, a US electronic parts manufacturer based in Wisconsin, replaced its legacy security system with an advanced security system consisting of biometric time-clock auditing, plus Matrix Systems' mobile surveillance and access control systems to improve profitability and secure doors. Matrix also upgraded the resolution of seven existing Ganz analog cameras, which helped Norstan save US$3,000. The analog cameras were integrated with Geovision software and hardware, and another 10 Geovision high-resolution cameras were added to cover the 3,716-square-meter (30,000-square-foot) facility.

Many CEO's think their security systems are just for opening doors, but John Nordigian, CEO of Norstan, envisioned video monitoring of his plant from anywhere in the world with his mobile phone, and state-of-the-art security technology to  reduce insurance costs, attract and retain Fortune 500 clients. One of the technological challenges during installation was finding a solution that could integrate with its existing five-door HID format key fob door reader system, which would cost approximately $2,800 to replace and install.

Matrix Systems enterprise-based access control system, which uses Mercury and HID access controller subsystems and its open architecture features allowed integration of third party technology. For larger views in remote locations, Nordigian can use a notebook computer, or unlock doors, respond to alarms and most other security functions via mobile apps that connect to the plant's access control system security workstation server from remote locations.

The main challenge, though, was integrating Nordigian's iPhone and Droid-X mobile apps, and his laptop computer into the upgraded video surveillance system.  Nordigian can now monitor any of the company's 17 video surveillance cameras anywhere within seconds through the access control security software using iPhone or Droix-X mobile apps. Matrix Systems built in functionality such as PTZ for closer looks. The CEO finds the iPhone's AT&T network more reliable abroad than the Droid-X's Verizon network, while domestically the iPhone's DGI software loading time and functionality, such as remote operating PTZ capabilities on surveillance cameras  outperformed Android GDA. The remote mobility feature is also capable of temporary access authorization, such as allowing an industrial service contractor into a secure area to repair a particular stamping machine. Future video improvements will include a conversion to IP to integrate into the access control system and add video voice-over to add audio capabilities for instant feedback and communication.

New cameras and digital recording capabilities through the access control system gave Norstan a hedge against illegal dumpers who potentially place illegal materials in the facility's dumpster, which could result in fines or recycling fees. Videos are stored on a NVR for 60 days.The mobile devices are also invaluable for afterhours alarm situations where Nordigian can go online within seconds after receiving an alarm phone call and inspect the entire plant from home or abroad.

Besides lowering operational costs, the new system is also attracting and retaining clients. "After we supplied the detailed plans of the installed the access control and GeoVision systems, a client was impressed with our system and commitment to protecting their on-site assets,” said Nordigan. “As a result, they chose to retain our services versus going to a competitor." Insurance carriers also took notice of the upgraded security system, which enabled Nordigian to negotiate a 10-percent insurance cost reduction.

Adding more functionality to Norstan's security was the impetus for replacing the prior access control system, which stopped providing updates for Microsoft SQL platforms and also crashed periodically. For example, many employee subgroups have been created for various authorization levels. Sensitive area access, such a precious metals inventories, tool areas and IT rooms are now accessible to employees authorized by the system with full audit trails provided by the new access control system. Employees see benefits as well, such as improved protection for personal property such as tools, autos and lockers. The system offers a safer work environment because of its capabilities of terminating potentially disgruntled former employee access just moments after dismissal.

EverFocus launches 16-CH 960H DVR

Editor / Provider: EverFocus Electronics | Updated: 5/20/2013 | Article type: Security 50

EverFocus is pleased to announce the launch of its new ECOR960 X1 16 channel, 120FPS 960H resolution DVR, targeting professional users with the highest image quality and the best recording experience. With a superior function set and an affordable price, while still providing critical CE, FCC and UL certifications, the ECOR960 X1 is especially ideal for homes, retails, SMB, and factory surveillance applications.

Thanks to its WD1 (960x480/960x576) resolution capabilities, the ECOR960 X1 digital video recorder gives users of the latest 960H cameras the ability to capture fast moving objects at enhanced detail levels, with a choice of WD1 or D1 formats. The new 16 channel ECOR960X1 also provides an upgrade to the ECOR264 feature set by incorporating 1080p Full HD Video output capability to VGA and HDMI monitors. Also available is an optional built-in DVD burner to preserve evidence and for secure video and data export.

The ECOR960 X1 can be used in complex multi-site installations when paired with powerful EverFocus centralized management software and tools, and is supported by the EverFocus MobileFocus line of remote video surveillance applications on iOS and Android devices, which help easily extend video surveillance from fixed location to mobile environments using a smartphone or pad devices.

Identive/Multicard launches integrated smart card and NFC school admin solution

Editor / Provider: Identive Group | Updated: 5/20/2013 | Article type: Security 50

Multicard, a supplier of credential solutions, identity management and system integration, and a business unit of Identive Group announced an integrated smart card solution that allows schools, universities and other educational institutions to verify student identities, track and report attendance, manage access to campus services and validate students' exam papers. The new student ID solution is based on the latest NFC and MIFARE DESFire EV1 contactless card technologies, ensuring the highest level of security and data validation capabilities, as well as significant ease of use for administrators and students alike.

“Our new Student Identification and Tracking Solution enables educational institutions to upgrade their existing identity management systems and benefit from the greater power, security and ease of use of contactless smart cards,” said Ross Head, MD of Multicard Australia. “We have been working with a number of universities that have assisted and guided us through the key issues that affect them most. The result is an integrated, comprehensive solution that encompasses registering students; issuing personalized student smart ID cards; verifying those ID cards at the door, at the library and for payment, parking and events; and validating exam results.”

Multicard's Student ID and Tracking solution allows educational institutions to interface to their existing student databases, retrieve student data and produce new student IDs based on secure contactless smart card technology. The new student IDs can be verified and logged with a quick tap to an NFC-enabled mobile device loaded with Multicard's mobile application – a portable verification station that can be located anywhere on campus, for example outside an exam room or sporting event. These information logs can be used to collate data for ongoing education credits, to verify attendance or for other purposes. To reduce testing fraud, the student ID cards can be visually confirmed and then scanned along with NFC tags attached to exam papers to track and validate the authenticity of the exam to the identity of the student. All data captured on the local NFC verification devices can later be securely transferred to a central web server where Multicard's management software can generate administrative reports. The solution is flexible and educational institutions can select the features they want initially and add to the system over time.
